Golf Course Bridge Sample Engineering Drawings

Use these typical PermaTrak concrete golf course bridge sections and engineering drawings in a client presentation or to discuss with your colleagues.

This free 12-page PDF contains several sets of boardwalk drawing examples for golf course bridges, including:

  • Typical plan, elevation and cross sections for PermaTrak's concrete boardwalk system
  • Straight and curved boardwalk sections with curb or railing system
  • Boardwalk details and foundation drawings samples

Complete the form to the right to download these sample golf course PermaTrak engineering drawings now.

For site-specific details, reach out to PermaTrak.

golf-course-drawings

Download the Sample Drawings

PermaTrak®

Our precast concrete boardwalk system was created to address the maintenance, safety and longevity issues presented by timber and composite decking boardwalk structures. We are grateful to work with thousands of landscape architects and engineers who choose to specify PermaTrak for its design, cost and installation benefits.
